Multi-Fact Queries

Overview

Multi-fact queries allow you to combine measures from multiple fact tables in a single query. PySemantic automatically detects when requested measures span different models and generates CTE-based SQL that avoids the chasm trap — a common pitfall where naive joins between fact tables produce inflated aggregates due to fan-out.

Conformed-Only Rule: Multi-fact queries require all dimensions to be conformed — reachable from every fact table in the query. Non-conformed dimensions raise NonConformedDimensionError. The only exception is Grand Total queries (no dimensions), which produce scalar aggregates via CROSS JOIN.

The Problem: Chasm Trap

Consider two fact tables — orders and web_events — both connected to a shared customers dimension:

orders ──FK──▶ customers ◀──FK── web_events

A naive join produces a Cartesian product between the two fact tables for each customer:

-- WRONG: Chasm trap — aggregates are inflated
SELECT
  c.name,
  SUM(o.revenue) AS total_revenue,
  COUNT(w.id) AS total_clicks
FROM customers c
LEFT JOIN orders o ON c.id = o.customer_id
LEFT JOIN web_events w ON c.id = w.customer_id
GROUP BY c.name;

If a customer has 3 orders and 5 web events, the join produces 15 rows per customer. SUM(revenue) is inflated 5x and COUNT(clicks) is inflated 3x.

The Solution: CTE-Based Pre-Aggregation

PySemantic solves this by pre-aggregating each fact table independently in a CTE, then joining the results on the shared conformed dimension:

WITH cte_orders AS (
  SELECT
    customers.id AS __pk_customers,
    customers.name AS customer_name,
    SUM(orders.revenue) AS total_revenue
  FROM orders
  LEFT JOIN customers ON orders.customer_id = customers.id
  GROUP BY 1, 2
),
cte_web_events AS (
  SELECT
    customers.id AS __pk_customers,
    customers.name AS customer_name,
    COUNT(web_events.id) AS total_clicks
  FROM web_events
  LEFT JOIN customers ON web_events.customer_id = customers.id
  GROUP BY 1, 2
)
SELECT
  COALESCE(cte_orders.customer_name, cte_web_events.customer_name) AS customer_name,
  cte_orders.total_revenue,
  cte_web_events.total_clicks
FROM cte_orders
FULL OUTER JOIN cte_web_events
  ON cte_orders.__pk_customers = cte_web_events.__pk_customers;

Each CTE aggregates at the correct grain. The FULL OUTER JOIN ensures customers that appear in only one fact table are still included.

How PySemantic Handles It

1. Detection — When you pass measures from more than one model, the planner switches to the multi-fact path instead of a single flat query.
2. Conformed dimensions — Every dimension you use (in SELECT or filters) must be reachable from every fact table in the query; otherwise PySemantic raises NonConformedDimensionError.
3. CTE per fact — Each fact table becomes one CTE that pre-aggregates its measures and joins to the shared dimension(s). No fact table is joined directly to another fact table, so there is no fan-out.
4. Outer join — The final query joins the CTEs on the shared dimension (by primary key or by dimension values) using FULL OUTER JOIN, so rows that exist in only one fact are still returned.
5. Intelligent Filter Pushdown — Filters are automatically routed to the right place: conformed dimension filters are pushed into every CTE's WHERE clause; non-conformed dimension filters (Grand Total only) are pushed into only the CTEs that can reach them; measure filters are applied to the outer query after CTE aggregation. No manual filter routing required.
6. Grand Total exception — If you request no dimensions at all, you get one row per CTE and a CROSS JOIN; non-conformed dimension filters are then allowed and applied only where reachable.

The same query() API is used for both single-fact and multi-fact; no extra configuration is required.

Conformed Dimensions

A conformed dimension is one that is reachable from every fact table in the query via the entity graph. Only conformed dimensions may appear in the SELECT or filter clauses of a multi-fact query. This ensures all CTEs group and filter at the same grain, producing correct aggregates.

PySemantic automatically detects how to reach each dimension from each fact table. If a model provides both measures and dimensions (e.g. customers has total_customers and customer_state), PySemantic handles this transparently — the model's own CTE uses local dimensions directly, while other CTEs join to it through the entity graph.

sl.query(
    measures=["total_order_price", "total_customers"],  # order_items + customers
    dimensions=["customer_state", "customer_city"],       # conformed: reachable from both facts
    filters=[{"field": "customer_state", "operator": "IN", "value": "('SP', 'RJ')"}],
)

Generates:

WITH cte_order_items AS (
  SELECT customer_state, customer_city, SUM(price) AS total_order_price
  FROM order_items
  LEFT JOIN orders ON ...
  LEFT JOIN customers ON ...
  WHERE customer_state IN ('SP', 'RJ')
  GROUP BY 1, 2
),
cte_customers AS (
  SELECT customer_state, customer_city, COUNT(customer_id) AS total_customers
  FROM customers
  WHERE customer_state IN ('SP', 'RJ')
  GROUP BY 1, 2
)
SELECT
  COALESCE(cte_order_items.customer_state, cte_customers.customer_state) AS customer_state,
  COALESCE(cte_order_items.customer_city, cte_customers.customer_city) AS customer_city,
  cte_order_items.total_order_price,
  cte_customers.total_customers
FROM cte_order_items
FULL OUTER JOIN cte_customers
  ON cte_order_items.customer_state = cte_customers.customer_state
  AND cte_order_items.customer_city = cte_customers.customer_city;

A non-conformed dimension — one that only some fact tables can reach — is rejected:

sl.query(
    measures=["total_order_price", "total_customers"],
    dimensions=["order_status"],  # only reachable from order_items, NOT from customers
)
# → raises NonConformedDimensionError

---

Usage

Multi-fact queries require no API changes. The existing SemanticLayer.query() method automatically detects and handles them. Both initialization styles work identically:

From model directoryFrom explicit model list

from pysemantic.client import SemanticLayer

sl = SemanticLayer(model_path="./models", dialect="postgres")

# Single-fact query (unchanged behavior)
sql = sl.query(
    measures=["total_revenue", "order_count"],
    dimensions=["customer_name"],
)

# Multi-fact query (automatic CTE generation)
sql = sl.query(
    measures=["total_revenue", "total_clicks"],  # from different fact tables
    dimensions=["customer_name"],                 # conformed dimension
)

from pysemantic.client import SemanticLayer
from pysemantic.modeling import Model, Dimension, Measure, Entity, EntityType

orders = Model(
    name="orders", table="orders", primary_key="order_id",
    measures=[Measure(name="total_revenue", agg="sum", column="revenue")],
    entities=[Entity(name="order", entity_type=EntityType.PRIMARY, column="order_id"),
              Entity(name="customer", entity_type=EntityType.FOREIGN, column="customer_id")],
)
web_events = Model(
    name="web_events", table="web_events", primary_key="event_id",
    measures=[Measure(name="total_clicks", agg="count", column="id")],
    entities=[Entity(name="event", entity_type=EntityType.PRIMARY, column="event_id"),
              Entity(name="customer", entity_type=EntityType.FOREIGN, column="customer_id")],
)
customers = Model(
    name="customers", table="customers", primary_key="customer_id",
    dimensions=[Dimension(name="customer_name", column="name", dtype="string")],
    entities=[Entity(name="customer", entity_type=EntityType.PRIMARY, column="customer_id")],
)

sl = SemanticLayer(models=[orders, web_events, customers], dialect="postgres")

sql = sl.query(
    measures=["total_revenue", "total_clicks"],
    dimensions=["customer_name"],
)

With Filters

In Conformed mode (dimensions present), all filter dimensions must also be conformed — reachable from every fact. Non-conformed filter dimensions raise NonConformedDimensionError.

# Conformed dimension filter — pushed into BOTH CTEs
sql = sl.query(
    measures=["total_revenue", "total_clicks"],
    dimensions=["customer_name"],
    filters=[{"field": "customer_name", "operator": "=", "value": "Alice"}],
)

# Non-conformed filter dimension — REJECTED
# order_date is only reachable from orders, not web_events
sl.query(
    measures=["total_revenue", "total_clicks"],
    dimensions=["customer_name"],
    filters=[{"field": "order_date", "operator": ">", "value": "2024-01-01"}],
)
# → raises NonConformedDimensionError

# Measure filter — applied to the outer query WHERE clause (always allowed)
sql = sl.query(
    measures=["total_revenue", "total_clicks"],
    dimensions=["customer_name"],
    filters=[{"field": "total_revenue", "operator": ">", "value": 100}],
)

Grand Total (No Dimensions)

When no dimensions are specified, each CTE produces a single aggregated row and the final query uses CROSS JOIN. This is the only way to query unrelated fact tables that share no conformed dimensions.

sql = sl.query(measures=["total_revenue", "total_clicks"])
# Produces:
# WITH cte_orders AS (SELECT SUM(revenue) AS total_revenue FROM orders),
#      cte_web_events AS (SELECT COUNT(id) AS total_clicks FROM web_events)
# SELECT cte_orders.total_revenue, cte_web_events.total_clicks
# FROM cte_orders CROSS JOIN cte_web_events;

In Grand Total mode, non-conformed filter dimensions are allowed and routed only to the CTEs that can access them:

# Grand Total with fact-specific filter — allowed
sql = sl.query(
    measures=["total_order_price", "total_customers"],
    dimensions=[],
    filters=[{"field": "order_status", "operator": "=", "value": "delivered"}],
)
# → order_status filter pushed only to order_items CTE
#   customers CTE produces unfiltered total

3+ Fact Tables

Multi-fact queries support any number of fact tables. Subsequent CTEs are joined using COALESCEd keys:

sql = sl.query(
    measures=["total_revenue", "total_clicks", "return_count"],
    dimensions=["customer_name"],
)

Produces chained FULL OUTER JOIN:

FROM cte_orders
FULL OUTER JOIN cte_web_events
  ON cte_orders.__pk_customers = cte_web_events.__pk_customers
FULL OUTER JOIN cte_returns
  ON COALESCE(cte_orders.__pk_customers, cte_web_events.__pk_customers)
     = cte_returns.__pk_customers

---

Architecture

How It Works Internally

The multi-fact feature extends the existing three-stage pipeline:

QueryAST  ──▶  QueryPlanner  ──▶  SQLGenerator
                    │                    │
              ┌─────┴─────┐        ┌────┴────┐
              │ QueryPlan │        │ Flat SQL │   (single-fact)
              └───────────┘        └─────────┘
              ┌───────────────┐    ┌──────────┐
              │ MultiFactPlan │    │ CTE SQL  │   (multi-fact)
              └───────────────┘    └──────────┘

Detection: The planner groups requested measures by their owning model. If all measures belong to one model, the existing QueryPlan path is used. If measures span 2+ models, the MultiFactPlan path activates — validating that all dimensions are conformed before generating SQL.

Data Structures

SharedDimensionKey

Represents a join key derived from a conformed dimension model's primary key. Used to join CTEs in the outer query when the dimension model is a dedicated dimension table (not also a fact in the query).

Field	Description
dimension_model_name	Name of the dimension model (e.g., "customers")
table_name	Physical table name (e.g., "customers")
primary_key_column	PK column name (e.g., "id")
alias	Internal alias for CTE output (e.g., "__pk_customers")

SubPlan

Represents a single CTE in the multi-fact query. One per fact table.

Field	Description
cte_alias	CTE name (e.g., "cte_orders")
fact_model_name	Semantic model name
fact_table_name	Physical table name
measures	Measures from this fact
dimensions	Conformed dimensions to include
joins	Join path from fact to dimension tables
shared_keys	Dimension PKs for outer-query joining
filters	Dimension filters pushed into this CTE

MultiFactPlan

The top-level plan containing all CTEs and outer-query metadata.

Field	Description
sub_plans	List of SubPlan instances
shared_dimensions	Conformed dimensions in the final SELECT
shared_keys	PK-based join keys (dedicated dimension models)
dimension_value_keys	Dimension names used as join keys (when the dimension model also provides measures in this query)
measure_filters	Filters applied to the outer query
order_by	ORDER BY fields for the outer query
limit	LIMIT for the outer query

---

Intelligent Filter Pushdown

PySemantic automatically routes every filter to the correct SQL location — no manual intervention needed. The routing strategy depends on the filter type and whether the query has dimensions.

┌─────────────────────────────────────────────────────┐
│                 Filter Pushdown                     │
│                                                     │
│  Dimension filter ─┬─ Conformed ──▶ ALL CTEs WHERE  │
│                    └─ Non-conformed                  │
│                       ├─ Conformed mode ──▶ ERROR    │
│                       └─ Grand Total ──▶ Reachable   │
│                                          CTEs only   │
│                                                     │
│  Measure filter ──────────────▶ Outer query WHERE   │
└─────────────────────────────────────────────────────┘

Conformed Mode (dimensions present)

Filter Type	Routing	Non-conformed?
Conformed dimension filter	Pushed into ALL CTEs' WHERE	Must be conformed — error if not
Measure filter	Applied to outer query WHERE	N/A

All dimension filters must be conformed (reachable from every fact). This guarantees symmetric filtering — every CTE applies the same dimension constraints, so aggregates remain comparable across fact tables.

# customer_city is conformed (reachable from both order_items and customers)
# → pushed into BOTH CTEs' WHERE clause
sql = sl.query(
    measures=["total_order_price", "total_customers"],
    dimensions=["customer_state"],
    filters=[{"field": "customer_city", "operator": "=", "value": "São Paulo"}],
)

Grand Total Mode (no dimensions)

Filter Type	Routing	Non-conformed?
Conformed dimension filter	Pushed into ALL CTEs' WHERE	Allowed
Fact-specific dimension filter	Pushed into ONLY accessible CTEs	Allowed
Measure filter	Applied to outer query WHERE	N/A

In Grand Total mode, non-conformed dimension filters are permitted. They're routed only to CTEs that can reach the dimension's model, producing asymmetric but semantically valid scalar aggregates.

# order_status is only reachable from order_items (via orders), NOT from customers
# → filter pushed ONLY to cte_order_items; cte_customers runs unfiltered
sql = sl.query(
    measures=["total_order_price", "total_customers"],
    dimensions=[],
    filters=[{"field": "order_status", "operator": "=", "value": "delivered"}],
)

WITH cte_order_items AS (
  SELECT SUM(order_items.price) AS total_order_price
  FROM order_items
  LEFT JOIN orders ON order_items.order_id = orders.order_id
  WHERE orders.order_status = 'delivered'   -- ← filter pushed here only
),
cte_customers AS (
  SELECT COUNT(customers.customer_id) AS total_customers
  FROM customers                            -- ← no filter (can't reach orders)
)
SELECT
  cte_order_items.total_order_price,
  cte_customers.total_customers
FROM cte_order_items
CROSS JOIN cte_customers;

Measure Filters

Measure filters are always applied to the outer query's WHERE clause (after CTE aggregation). Since CTEs already compute the aggregated values, these become simple column comparisons like cte_orders.total_revenue > 100.

---

Error Handling

Multi-fact queries introduce three exception classes following the existing exception hierarchy:

NonConformedDimensionError (inherits from MultiFactPlanningError)

The primary guard for multi-fact queries. Raised when a dimension (SELECT or filter) is not conformed — not reachable from every fact table in the query.

from pysemantic.core.planner import NonConformedDimensionError

try:
    sql = sl.query(
        measures=["total_order_price", "total_customers"],
        dimensions=["order_status"],  # only reachable from order_items, not customers
    )
except NonConformedDimensionError as e:
    print(e)
    # planning.multi_fact: Non-conformed Dimension requested
    # (details="Dimension 'order_status' (model 'orders') is not reachable
    #  from fact model 'customers'. In multi-fact queries all dimensions must
    #  be conformed — joinable from every fact table. For unrelated facts with
    #  no shared dimensions, use a Grand Total query (no dimensions).")

MultiFactPlanningError (inherits from PlannerError)

Raised for general multi-fact planning issues:

• Invalid measure filter: A filter references a measure from a model that isn't a fact table in the query
• Missing dimension/measure definitions: A referenced field doesn't exist in any model
• Join path not found: A CTE can't join to a required dimension model

MultiFactGenerationError (inherits from GeneratorError)

Raised during SQL generation when:

• Empty sub-plans: MultiFactPlan has no CTEs to generate
• Empty CTE SELECT: A CTE produces no output columns
• Unresolvable dimension in CTE: A dimension can't be found in the CTE's accessible models
• Unresolvable measure in outer query: A measure filter references a field not in any CTE

---

Constraints and Limitations

Conformed Dimension Requirement

1. All dimensions must be conformed — reachable from every fact table in the query via the entity graph. Non-conformed dimensions in either SELECT or filter clauses raise NonConformedDimensionError.

2. Grand Total exception: the only way to query unrelated fact tables is with no SELECT dimensions, producing scalar aggregates via CROSS JOIN. Non-conformed filter dimensions are permitted in this mode.

3. Models providing both measures and dimensions are fully supported. When a model contributes both measures and conformed dimensions to a query, PySemantic uses dimension-value joins instead of PK-based joins to preserve correct aggregate semantics.

Dialect Support

PySemantic defaults to MySQL and supports all dialects via SQLGlot. Pass the dialect parameter when initializing SemanticLayer:

sl = SemanticLayer(model_path="./models", dialect="postgres")

Dialect	Value	Multi-Fact Notes
MySQL	"mysql" (default)	2-fact supported (SQLGlot transpiles FULL OUTER JOIN to LEFT + RIGHT + UNION ALL). 3+ facts may need native FULL OUTER JOIN.
PostgreSQL	"postgres"	Full support (native FULL OUTER JOIN)
BigQuery	"bigquery"	Full support
Snowflake	"snowflake"	Full support
DuckDB	"duckdb"	Full support
Databricks	"databricks"	Full support
Redshift	"redshift"	Full support
ClickHouse	"clickhouse"	Full support
Trino / Presto	"trino" / "presto"	Full support
SQLite	"sqlite"	Limited (FULL OUTER JOIN not natively supported)
... and more	See SQLGlot dialect list

Impact on Existing System

Component	Impact
plan.py	Added SharedDimensionKey, SubPlan, MultiFactPlan (with dimension_value_keys for dimension-value joins)
planner.py	Added MultiFactPlanningError, NonConformedDimensionError, _plan_multi_fact(), _find_shared_dimension_owner(), _validate_dimension_conformity(), _is_reachable_from_all(), _can_reach(). Conformed-only enforcement with Grand Total exception. Existing single-fact logic in _plan_single_fact() — no behavioral change
generator.py	Added MultiFactGenerationError, _build_multi_fact_sql(), _build_cte_body(), _build_cte_joins() (supports both PK-based and dimension-value joins), _build_measure_filter_where(), _find_owner_model_in_subplan(). Existing single-fact methods unchanged
client.py	No changes — polymorphic flow handles both plan types
exceptions.py	No changes — new exceptions inherit from existing base classes
registry.py	No changes
ast.py	No changes

The feature is fully backward-compatible. Single-fact queries follow the exact same code path as before.
